SMPS CM ELITE GOLD 750W

Features	Specification
Product Name	ELITE GOLD 750
Model	MPX-7505-AFAG
Series	Elite Series
Form Factor	ATX
ATX Version	ATX 12V Ver. 3.1
Power Output	750W
Modular Type	Fully Modular
PFC	Active PFC
Input Voltage	100–240V
Input Current	5 ~ 10A
Input Frequency	50–60Hz
Dimensions (L × W × H)	140 × 150 × 86 mm
Fan Size	120mm
Fan Bearing	Rifle Bearing
Efficiency	≥90% @ Typical Load
80 PLUS Rating	80 PLUS Gold
80 Plus Efficiency	Gold
ErP 2014 Lot 3	Yes
Operating Temperature	0°C – 40°C
Power Good Signal	100 – 150 ms
Hold Up Time	≥11ms @ 100% Load
MTBF	>100,000 Hours @ 25°C Ambient
Protections	UVP / OVP / OPP / OTP / SCP
Regulatory Certifications	cTUVus, CB, CE, FCC, BSMI, CCC, RCM, UKCA, BIS, RoHS2.0
ATX 24 Pin Connectors	x1 (550mm)
EPS 4+4 Pin / EPS 8 Pin Connectors	x2 = 1 (600+120mm)
SATA & Peripheral 4 Pin Connectors	X4(s) + x2(p) = 2 [400(s)+120(s)+120(p) mm]
PCI-e 6+2 Pin Connectors	x2 = 1 (500+120mm)
12+4 Pin Connectors	x1 (650mm)
Warranty	10 Years
